Matthew Kerner's Panorama Project

In order to view the Panoramas you will have to have Java installed.  I have added some comments on the project and extra credit notes below the images.

Carpool Panorama (Kaidan)

Created with a Canon PowerShot S10 and a Kaidan head

Panorama

Office Panorama (Kaidan)

Created with a Canon PowerShot S10 and a Kaidan head

Panorama

Office Panorama (free)

Created with a Canon PowerShot S10

Panorama

Tutoring Panorama (Kaidan)

Created with a Canon PowerShot A10 (CS30012716) and a Kaidan head

Panorama

Tutoring Panorama (free)

Created with a Canon PowerShot A10 (CS30012716)

Panorama

Sample Image

Created from the sample images provided for the project

Panorama

I created these Panoramas using cylindrical warping, Lucas-Kanade motion estimation & feathered blending. There were several lessons learned:

• Observations on what worked well and what didn't work well
• The Kaidan head makes a huge difference as I am evidently very bad at taking panoramas without a tripod.
• Stitch assist does help somewhat.
• The Kaidan head makes it possible to estimate a displacement between one pair of adjacent images, and reuse it as the Lucas Kanade seed for all image pairs in the sequence.
• Without the Kaidan head, it is necessary to manually fine-tune the seed, and reduce the L-K levels and steps to minimize the displacement that it adds on top of the seed.  Interactive manual adjustment would be a useful feature for these sequences.
• For free sequences, it would be useful to have a rotation-based correction in the software.  There were several image pairs that I couldn't line up properly because the transformation was not a simple (u,v) displacement.  With SIFT, this would not be an issue: I could calculate the rotation, or a general affine warp, to make the images align properly.
• There were several adjacent image pairs whose interface contained very few contrasting pixels.  These required additional manual alignment.  For example, the tutoring panoramas contained image pairs that met just to the left-hand side of the door to the room.  The only contrasting pixels were located around the recycling box near the bottom of the image.  I had to manually tweak the initialization parameters before I could get the parts of the box to line up properly.  SIFT or brute-force search with a least-squared error function would be a good way to discover an optimal seed without manual intervention.
• In the tutoring free sequence, there were two pairs of adjacent images which were taken such that they didn't overlap at all.  I had to reduce Lucas Kanade to one level with one iteration, and manually align the images as close as possible.  This is where stitch assist makes a big difference.
• You can see one just to the left of the first computer near the door
• You can see the other just to the left of the left-hand computer below the windows
• Vertical drift is an issue, regardless of whether or not the photos were taken with the Kaidan head.
• The camera parameters (focal-length, k1, k2) are important.  I was unable to line up the images that I took with my own digital camera exactly, because I didn't have those parameters and I didn't have a chance to use the camera calibration kit to find them.
• Extra Credit/Non-Standard Implementation
• Rather than just cropping the image on the x-axis, I also cropped the image on the y-axis to eliminate the areas that were empty due to vertical drift.  Some of my image sequences went clockwise, and others went counter-clockwise.  When cropping the vertical drift, I had to adjust the relative locations of images in order to account for the direction in which the image was stitched together.  That is, I adjusted the signs of the x- and y-deltas to account for the camera's varied rotation.
• I noticed that the sample solution made intelligent decisions on when to crop based on the slope of the vertical drift over the images.  I implemented similar logic to crop vertically only when the slope was negative (leaving a croppable area below the bottom row of the lowest image).  When the slope was positive I did not crop the image.  This logic worked well across all of my images.  Only the tutoring images had positive slope.
• I did not implement the following areas, but I have some thoughts on them:
• Exposure differences -  when adjacent images had different exposure, it made the brightness fluctuate across the final stitched image.  You can see this in the sample image, or in the image taken in my office with the Kaidan head.  I had two thoughts on how I could remove the fluctuation.
1. The first is to minimize the sum of the squared difference in brightness across pixels that lie on top of one another after the displacement has been applied, before blending the image.  This can be done by altering the brightness of the new image to blend by a constant across all pixels before blending it.  A good guess of an initial constant can be discovered by taking the average of the brightness differences for overlapping pixels as a seed, and then adjusting that seed as necessary.  This has the effect of taking a brightness "threshold" at the overlapped area of the first image, and then adjusting each subsequent image by that threshold plus any accumulated changes in brightness across the panorama.  Of course, "brightness drift" might accumulate with this method, and it would be necessary to apply a similar correction as the one we applied for vertical drift to fix this problem (i.e. distribute parts of the brightness error across all images equally).  Another downside of this approach is that the Lucas-Kanade step does not benefit from the brightness adjustment (i.e. improved brightness adjustments don't improve the L-K motion estimation because they are applied afterwards).  One way to fix this is to put the algorithm in a loop and bootstrap it.  In other words, find the initial Lucas-Kanade estimate, correct brightness, and repeat until convergence.
2. The second is to automatically normalize object brightness across all images containing an image of an object.  Perhaps the target brightness could be the mean brightness of the object across all affected images.  Of course this would require object recognition.  Two options would be (a) to get human input to identify objects and (b) to use SIFT to identify common objects across images.
• Ghosted object removal - some of my images contained ghosted objects (e.g. the moving heads and the cars seen through the window in the carpool image).  One way to remove these objects would be to create a mask (e.g. using the intelligent scissors tool from the previous project) and applying full transparency to the area within that mask in the images containing the ghosts to be removed.
• AutoStitch - I did not implement autostitch, but I did try it out.  It is a remarkable program.  I was able to stitch a landscape scene of 18 images together into an attractive panorama in under 30 seconds.  I had two ideas of how this functionality could be used for novel applications.
1. In the early 20th century, Stirling Moss drove 1,000 miles in 10 hours at an average speed of over 100 miles per hour on small Italian country roads in his Mercedes race-car.  Find out more here (listen to the last part of the show).  The only way that he succeeded at this was by practicing the route in advance, with his navigator taking detailed notes of what would come up along the way.  If cameras could be mounted along the sides of the car during the preparatory drive, it would be possible to use autostitch to assemble two extremely long panoramas - one from each side of the car.  The driver could then train for the drive by using the panoramas to learn the course.  Similarly, the navigator could use the panoramas on the race day to tell the driver what is coming up next.
2. Tourists who travel by train could set up time-lapse cameras pointing out the window.  Autostitch could be used to compose the images taken by such cameras into a mosaic, which could then be put on video in a long, slow pan from one side to the other.  Then, rather than watching slides in a slide projector, relatives could fall asleep watching videos of the train ride.

See the project's homepage here.
