CSE576 - Computer Vision

Project 2 - Panorama Stitching

Approach

• Spherical Warping: This transforms the image so that alignment only requires direct translation.


  Original image taken by a digital camera	Image warped for a focal length of 595 pixels and radial compensation with k1=-.15,k2=0.0.

• RANSAC based Image Alignment: The detected feature correspondences are sampled at random, with the strongest correspondence (according to a count of inliers) taken to be the actual alignment.
• Final Image Compositing: The individual images are composed using the alignment information, and feathering is used to smoothly blend the transitions between overlapping images.

Experience

I tried using both the sift feature descriptors and my custom descriptor from Project 1. The alignments obtained using the sift descriptors were far better than my own, so those alignments were used to produce the final output. My own descriptors were much faster, however. I believe a large portion of this speedup comes from a more efficient feature matching scheme. I compute three characteristic values in my descriptor which are the percentage of the overal value that lies in the top, left, and diagonal quadrants of the descriptor patch. In the match routine, I first compare these values, and if they are not within a threshold percentage, I don't consider it to be a feature match and I skip the expensive Euclidian distance computation.

I also found that one size doesn't fit all when it comes to the RANSAC parameters. After tweaking them by hand, I could get settings that would come up with a reasonable alignment for most of a whole set of images, but there would be a pair or two that were still largely misaligned. The panoramas shown in the results were generated by finding a good set of parameters for most of the images, and then going back and re-running the alignment for those that were far off with different parameters until reasonable results were obtained.

Results

Panorama 1: Test Data Set

Here are the results for the test set provided with the project. The algorithm performed the best on this data.

Panorama 2: Snoqualamie Falls using Kaiden Head Tripod

This test set was taken from the boardwalk at Snoqualamie Falls using a tripod to help with positioning and rotating of the camera. This data was harder to work with, and there is still quite a bit of ghosting.

Panorama 3: Snoqualamie Falls Handheld

This data was taken from the same observation point, this time the camera was held and I spun as I took pictures. The angle between images is far less regular, and they aren't aligned horizontally nearly as well. The auto stitching had the most trouble with this data set, and even after fiddling, there is a large discontinuity in the middle of the panorama.
